FOD3120 3120 smd

استفاده در انواع صنایع از جمله بردهای درایو دستگاه های جوش و برش و اینورتری
مخابراتی
مدارات عمومی
درایورهای دور موتور و .....

مشخصات بیشتر:


Features

High noise immunity characterized by 35kV/µs minimum common mode rejection
2.5A peak output current driving capability for most 800V/20A IGBT
Use of P-channel MOSFETs at output stage enables output voltage swing close to the supply rail
Wide supply voltage range from 15V to 30V
Fast switching speed
400ns max. propagation delay
100ns max. pulse width distortion
Under-Voltage LockOut (UVLO) with hysteresis
Extended industrial temperate range, -40°C to 100°C temperature range
Safety and regulatory approved
UL1577, 5000 VRMS for 1 min.
IEC60747-5-2
RDS(ON) of 3Ω (typ.) offers lower power dissipation
>8.0mm clearance and creepage distance (option ‘T’)
Uninterruptible Power Supply
Industrial Inverter
Isolated IGBT/Power MOSFET Gate Drive
Induction Heating
Applications
AC-DC Merchant Power Supply
Energy Generation & Distribution
Industrial Motor
Uninterruptible Power Supply
