Item #: AGD-62
Item Name: Model AGD Double Acting/Single Stage Pneumatic Driven Gas Booster
Maximum Rated Gas Supply: 9000 psig
620 bar
Minimum Rated Gas Supply: 14 bar
200 psig
Maximum Rated Gas Outlet Pressure for Inert Gas: 9000 psig
620 bar
Maximum Rated Gas Outlet Pressure for Oxygen: 5000 psig
345 bar
Maximum Rated Gas Outlet Pressure for Hydrogen: 9000 psig
620 bar
Static Outlet Stall Pressure: 60 Pa+Ps
Piston Displacement per Cycle: 6.2 in³
101.6 mL
Gas Inlet/Outlet Connections: Interchangeable 3 3/8 in SAE or 1/4 in - H/P both Ports.
2 ea Inlet and Outlet
Weight: 49 lb
22 kg
Air Drive Inlet Port Size: 1/2 in FNPT
Suitable Gas for Transfer and Pressurization: Nitrogen (N2)
Helium (He)
Breathing Air (N2O2)
Nitrous Oxide (N2O)
Carbon Dioxide (CO2)
Neon (Ne)
Argon (Ar)
Sulfur Hexafluoride (SF6)
Oxygen (O2)
Carbon Monoxide (C)
Hydrogen (H2
Methane (CH4)
Ethylene (C2H4)
Deuterium (D2)
Natural Gas (CH4)
